Catalog

Datasheet

Specification

General
CPU 1.8GHz QUAD-Core
NPU O (2.3 TOPS)
Memory Flash 16GB eMMC
RAM 4GB (LPDDR4)
LCD type 5′ (TFT IPS LCD)
Resolution 720 x 1280
Speaker Audio Codec IW
MIC Waterproof MIC
Operating Temparature 20℃ ~ 60℃
Operating Humidity 0% ~ 90%, non-condensing
Weight 336g
Dimension (W x H x D) mm 92x200x21
Impact Protection IK06
IP Rating IP65
Certificates CE / FCC / KC / BIS / RoHs / WPC
Biometrics
Face Recognition Distance 0.5M ~ 2M
Matching Speed <1 sec
Liveness Detection O
Fingerprint Template UNION / IS019794-2 / ANSI-378
Extractor / Matcher MINEX certified & compliant
Image Dimension 256*292
Resolution 500 DPI
LiveFinger Detection O
RF
RF Read Range EM 50 mm
Smart Card 50 mm
DESFIRE EV1 / EV2 / EV3 45 mm
FELICA 30 mm
RF Option 125KHz EM All in One
13.56MHz Smart Card
Mifare (Plus)
Felica
ISO14443 A/B
ISO 15693
DESFIRE EV1 / EV2 / EV3
HID Prox Option
HID iCLass Option
Mobile Card
NFC O
BLE O
QR
Image Sensor 640 x 480
Symbologies 1D / 2D
FOV(H x V) 42℃ X 31.5℃
Mobile Phone (iOS) Iphone: iOS 10.0 or above / BLE4.2 or above
Mobile Phone (Android) Android 6.0 or above / NFC Supported Device
Encryption Azure Key Vault / AES-128
Recognition Distance 10cm (difference in models)
Server Platform On Premise / Cloud
Capacity
Face 1:N 30,000
1:1 30,000
Fingerprint 1:N 50,000
1:1 5,00,000
Event Log 1,00,00,000
Picture Log 20,000
Interface
Ethernet 10/ 100M / 1000M 1 Port
RS-485 1 Port
RS-232 2 Port
Wiegand IN / OUT 1 Port
Relay 2 Port
USB 2.0 1 Port
Wifi O
Power
Voltage DC 15V ~ 24V
Current Max 1.1A @DC15V
